VHM HPC Bohrreibahle 3xD mit IK Ø 6,0 mm, ± 0,003, Typ BR100-03IK
81,20 €
entspricht 96,63 € inkl. MwSt. (19%) zzgl. Versandkosten
Produktnummer:
20119148
Produktinformationen "VHM HPC Bohrreibahle 3xD mit IK Ø 6,0 mm, ± 0,003, Typ BR100-03IK"
VHM HPC Bohrreibahle 3xD mit Innenkühlung IK, Typ BR100-03IK-HA
Diese VHM Bohrreibahle ist für die Bearbeitung von Stahl und Guss ausgelegt.
Die Spitzengeometrie mit 140° Spitzenwinkel garantiert ein sicheres Zentrieren.
- 3xD
- mit Innenkühlung
- Schaft: HA zylindrisch, Toleranz h6
VHM Bohrreibahle in 5xD BR100-05IK
| Maße | |||||||
| Toleranz | Ødc | lc | l2 | l1 | Ød1 | Art.-Nr. | |
|---|---|---|---|---|---|---|---|
| m7 | h6 | ||||||
| ± 0,003 | 3,97 | 17 | 24 | 66 | 6 | BR100-03IK-03.970HA | |
| ± 0,003 | 3,98 | 17 | 24 | 66 | 6 | BR100-03IK-03.980HA | |
| ± 0,003 | 3,99 | 17 | 24 | 66 | 6 | BR100-03IK-03.990HA | |
| ± 0,003 | 4,0 | 17 | 24 | 66 | 6 | BR100-03IK-04.000HA | |
| H7 | 4,0 | 17 | 24 | 66 | 6 | BR100-03IK-04.000HA | |
| ± 0,003 | 4,01 | 17 | 24 | 66 | 6 | BR100-03IK-04.010HA | |
| ± 0,003 | 4,02 | 17 | 24 | 66 | 6 | BR100-03IK-04.020HA | |
| ± 0,003 | 4,03 | 17 | 24 | 66 | 6 | BR100-03IK-04.030HA | |
| ± 0,003 | 4,97 | 20 | 28 | 66 | 6 | BR100-03IK-04.970HA | |
| ± 0,003 | 4,98 | 20 | 28 | 66 | 6 | BR100-03IK-04.980HA | |
| ± 0,003 | 4,99 | 20 | 28 | 66 | 6 | BR100-03IK-04.990HA | |
| ± 0,003 | 5,0 | 20 | 28 | 66 | 6 | BR100-03IK-05.000HA | |
| H7 | 5,0 | 20 | 28 | 66 | 6 | BR100-03IK-05.000HA | |
| ± 0,003 | 5,01 | 20 | 28 | 66 | 6 | BR100-03IK-05.010HA | |
| ± 0,003 | 5,02 | 20 | 28 | 66 | 6 | BR100-03IK-05.020HA | |
| ± 0,003 | 5,03 | 20 | 28 | 66 | 6 | BR100-03IK-05.030HA | |
| ± 0,003 | 5,97 | 20 | 28 | 66 | 6 | BR100-03IK-05.970HA | |
| ± 0,003 | 5,98 | 20 | 28 | 66 | 6 | BR100-03IK-05.980HA | |
| ± 0,003 | 5,99 | 20 | 28 | 66 | 6 | BR100-03IK-05.990HA | |
| ± 0,003 | 6,0 | 20 | 28 | 66 | 6 | BR100-03IK-06.000HA | |
| H7 | 6,0 | 20 | 28 | 66 | 6 | BR100-03IK-06.000HA | |
| ± 0,003 | 6,01 | 20 | 28 | 66 | 6 | BR100-03IK-06.010HA | |
| ± 0,003 | 6,02 | 20 | 28 | 66 | 6 | BR100-03IK-06.020HA | |
| ± 0,003 | 6,03 | 20 | 28 | 66 | 6 | BR100-03IK-06.030HA | |
| H7 | 7,0 | 24 | 34 | 79 | 8 | BR100-03IK-07.000HA | |
| ± 0,003 | 7,97 | 24 | 34 | 79 | 8 | BR100-03IK-07.970HA | |
| ± 0,003 | 7,98 | 24 | 34 | 79 | 8 | BR100-03IK-07.980HA | |
| ± 0,003 | 7,99 | 24 | 34 | 79 | 8 | BR100-03IK-07.990HA | |
| ± 0,003 | 8,0 | 24 | 34 | 79 | 8 | BR100-03IK-08.000HA | |
| H7 | 8,0 | 24 | 34 | 79 | 8 | BR100-03IK-08.000HA | |
| ± 0,003 | 8,01 | 24 | 34 | 79 | 8 | BR100-03IK-08.010HA | |
| ± 0,003 | 8,02 | 24 | 34 | 79 | 8 | BR100-03IK-08.020HA | |
| ± 0,003 | 8,03 | 24 | 34 | 79 | 8 | BR100-03IK-08.030HA | |
| H7 | 9,0 | 35 | 47 | 89 | 10 | BR100-03IK-09.000HA | |
| ± 0,003 | 9,97 | 35 | 47 | 89 | 10 | BR100-03IK-09.970HA | |
| ± 0,003 | 9,98 | 35 | 47 | 89 | 10 | BR100-03IK-09.980HA | |
| ± 0,003 | 9,99 | 35 | 47 | 89 | 10 | BR100-03IK-09.990HA | |
| ± 0,003 | 10,0 | 35 | 47 | 89 | 10 | BR100-03IK-10.000HA | |
| H7 | 10,0 | 35 | 47 | 89 | 10 | BR100-03IK-10.000HA | |
| ± 0,003 | 10,01 | 35 | 47 | 89 | 10 | BR100-03IK-10.010HA | |
| ± 0,003 | 10,02 | 35 | 47 | 89 | 10 | BR100-03IK-10.020HA | |
| ± 0,003 | 10,03 | 35 | 47 | 89 | 10 | BR100-03IK-10.030HA | |
| ± 0,003 | 11,97 | 40 | 55 | 102 | 12 | BR100-03IK-11.970HA | |
| ± 0,003 | 11,98 | 40 | 55 | 102 | 12 | BR100-03IK-11.980HA | |
| ± 0,003 | 11,99 | 40 | 55 | 102 | 12 | BR100-03IK-11.990HA | |
| ± 0,003 | 12,0 | 40 | 55 | 102 | 12 | BR100-03IK-12.000HA | |
| H7 | 12,0 | 40 | 55 | 102 | 12 | BR100-03IK-12.000HA | |
| ± 0,003 | 12,01 | 40 | 55 | 102 | 12 | BR100-03IK-12.010HA | |
| ± 0,003 | 12,02 | 40 | 55 | 102 | 12 | BR100-03IK-12.020HA | |
| ± 0,003 | 12,03 | 40 | 55 | 102 | 12 | BR100-03IK-12.030HA | |
| H7 | 14,0 | 43 | 60 | 107 | 14 | BR100-03IK-14.000HA | |
| H7 | 16,0 | 45 | 65 | 115 | 16 | BR100-03IK-16.000HA | |
| H7 | 18,0 | 51 | 73 | 123 | 18 | BR100-03IK-18.000HA | |
| H7 | 20,0 | 55 | 79 | 131 | 20 | BR100-03IK-20.000HA | |
| Anwendung: | Durchgangsloch, Pakete Bohren, Querbohrungen, Sackloch, Schraeger Austritt |
|---|---|
| Bohrtiefe xD: | 3xD |
| Einsatzgebiet: | K, P |
| HPC/HSC: | 4 Fasen, hpc, IK |
| Schneiden: | z2 |
| VHM/HSS(E): | vhm |
| Schneidenlänge: | 20 |
| Durchmesser: | 6,0 |
| Beschichtung: | beschichtet |
| Schaftform: | HA |
